AIC
|
-
|
02
|
-
|
04
|
-
|
31
|
|
1
|
|
2
|
|
3
|
|
4
|
|
1
|
Models
|
Through one-way valve
|
|
2
|
Dental mouth diameter
|
02：Rc1/4
|
|
03：Rc3/8
|
|
04：Rc1/2
|
|
3
|
Opening pressure of
|
04：0.04MPa
|
|
4
|
Model
（Material designation）
|
31：All stainless steel（SUS303）
|
|
|
●
|
Is the coolant for machine tools plant and water use and development of stainless steel (SUS303) through one-way valve。
|
|
●
|
In the water-soluble coolant, you can also use the water and industrial water, etc.。
|
|
●
|
All stainless steel check valve installed in the handling process of the coolant, and a long period can stop the operation to prevent rust caused by tightening the one-way valve。
|
|
●
|
Bad in the environment can advance the factory to prevent internal condensation and adverse conditions。
|
|
Maximum pressure
|
25MPa
|
|
Pressure-resistant
|
45MPa
|
|
For fluid
|
Shimizu
|
|
Model
|
Dental mouth diameter
|
Hex
|
Net weight
|
|
AIC-02-04-31
|
Rc1/4
|
21
|
120g
|
|
AIC-03-04-31
|
Rc3/8
|
26
|
220g
|
|
AIC-04-04-31
|
Rc1/2
|
30
|
320g
|
|
|
Data tables, flow rate - pressure drop characteristics
|
|
|
|
|
|
|
|
|
US-series
